Documentation

Welcome to Slinky, a set of powerful integration tools designed to bring Slurm capabilities into Kubernetes. Whether you’re managing high-performance computing (HPC) workloads or operating within cloud-native environments, Slinky helps bring together the best of both worlds for efficient resource management and scheduling.

1 - Overview

Slinky

Welcome to Slinky, a set of powerful integration tools designed to bring Slurm capabilities into Kubernetes. Whether you’re managing high-performance computing (HPC) workloads or operating within cloud-native environments, Slinky helps bring together the best of both worlds for efficient resource management and scheduling.

Slinky is made by SchedMD, the lead developers of Slurm.


2 - slurm-bridge

slurm-bridge

Run Slurm as a Kubernetes scheduler. A Slinky project.

Code Respository

The code repository can be accessed at https://github.com/SlinkyProject/slurm-bridge

Overview

Slurm and Kubernetes are workload managers originally designed for different kinds of workloads. In broad strokes: Kubernetes excels at scheduling workloads that typically run for an indefinite amount of time, with potentially vague resource requirements, on a single node, with loose policy, but can scale its resource pool infinitely to meet demand; Slurm excels at quickly scheduling workloads that run for a finite amount of time, with well defined resource requirements and topology, on multiple nodes, with strict policy, but its resource pool is known.

This project enables the best of both workload managers. It contains a Kubernetes scheduler to manage select workload from Kubernetes.

For additional architectural notes, see the architecture docs.

Supported Slurm Versions

Data Parser: v41

  • 24.05
  • 24.11

Overall Architecture

This is a basic architecture. A more in depth description can be found in the docs directory.


Known Issues

  • CGroups is currently disabled, due to difficulties getting core information into the pods.
  • Updates may be slow, due to needing to wait for sequencing before the slurm-controller can be deployed.

License

Copyright (C) SchedMD LLC.

Licensed under the Apache License, Version 2.0 you may not use project except in compliance with the license.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

2.1 - 0.3.x

2.1.1 - Overview

Slurm and Kubernetes are workload managers originally designed for different kinds of workloads. In broad strokes: Kubernetes excels at scheduling workloads that typically run for an indefinite amount of time, with potentially vague resource requirements, on a single node, with loose policy, but can scale its resource pool infinitely to meet demand; Slurm excels at quickly scheduling workloads that run for a finite amount of time, with well defined resource requirements and topology, on multiple nodes, with strict policy, but its resource pool is known.

This project enables the best of both workload managers. It contains a Kubernetes scheduler to manage select workload from Kubernetes.


For additional architectural notes, see the architecture docs.

Features

Slurm

Slurm is a full featured HPC workload manager. To highlight a few features:

  • Priority: assigns priorities to jobs upon submission and on an ongoing basis (e.g. as they age).
  • Preemption: stop one or more low-priority jobs to let a high-priority job run.
  • QoS: sets of policies affecting scheduling priority, preemption, and resource limits.
  • Fairshare: distribute resources equitably among users and accounts based on historical usage.

Limitations

  • Kubernetes Version: >= v1.29
  • Slurm Version: >= 25.05

Installation

Install the slurm-bridge scheduler:

helm install slurm-bridge oci://ghcr.io/slinkyproject/charts/slurm-bridge \
  --namespace=slinky --create-namespace

For additional instructions, see the quickstart guide.

License

Copyright (C) SchedMD LLC.

Licensed under the Apache License, Version 2.0 you may not use project except in compliance with the license.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

2.1.2 - Admission

Overview

The admission controller is a webhook for Pods. Any pods created in certain namespaces will be modified so our scheduler will schedule them instead of the default scheduler.

Design

Any pods created in certain namespaces will have their .spec.schedulerName changed to our scheduler.

Managed namespaces are defined as a list of namespace as configured in the admission controller’s values.yaml for managedNamespaces[].

Sequence Diagram

sequenceDiagram
  autonumber

  participant KAPI as Kubernetes API
  participant SBA as Slurm-Bridge Admission

  KAPI-->>SBA: Watch Pod Create/Update
  opt Pod in managed Namespaces
    SBA->>KAPI: Update `.spec.schedulerName` and Tolerations
    KAPI-->>SBA: Update Response
  end %% opt Pod in managed Namespaces

2.1.3 - Architecture

Overview

This document describes the high-level architecture of the Slinky slurm-bridge.

Big Picture


Directory Map

This project follows the conventions of:

api/

Contains Custom Kubernetes API definitions. These become Custom Resource Definitions (CRDs) and are installed into a Kubernetes cluster.

cmd/

Contains code to be compiled into binary commands.

config/

Contains yaml configuration files used for kustomize deployments

docs/

Contains project documentation.

hack/

Contains files for development and Kubebuilder. This includes a kind.sh script that can be used to create a kind cluster with all pre-requisites for local testing.

helm/

Contains helm deployments, including the configuration files such as values.yaml.

Helm is the recommended method to install this project into your Kubernetes cluster.

internal/

Contains code that is used internally. This code is not externally importable.

internal/controller/

Contains the controllers.

Each controller is named after the Custom Resource Definition (CRD) it manages. Currently, this consists of the nodeset and the cluster CRDs.

internal/scheduler/

Contains scheduling framework plugins. Currently, this consists of slurm-bridge.

2.1.4 - Controllers

Overview

This component is comprised of multiple controllers with specialized tasks.

Node Controller

The node controller is responsible for tainting the managed nodes so the scheduler component is fully in control of all workload that is bound to those nodes.

Additionally, this controller will reconcile certain node states for scheduling purposes. Slurm becomes the source of truth for scheduling among managed nodes.

A managed node is defined as a node that has a colocated kubelet and slurmd on the same physical host, and the slurm-bridge can schedule on.

sequenceDiagram
  autonumber

  participant KAPI as Kubernetes API
  participant SWC as Slurm Workload Controller
  participant SAPI as Slurm REST API

  loop Reconcile Loop
    KAPI-->>SWC: Watch Kubernetes Nodes

    alt Node is managed
      SWC->>KAPI: Taint Node
      KAPI-->>SWC: Taint Node
    else
      SWC->>KAPI: Untaint Node
      KAPI-->>SWC: Untaint Node
    end %% alt Node is managed

    alt Node is schedulable
      SWC->>SAPI: Drain Node
      SAPI-->>SWC: Taint Node
    else
      SWC->>SAPI: Undrain Node
      SAPI-->>SWC: Undrain Node
    end %% alt Node is schedulable

  end %% loop Reconcile Loop

Workload Controller

The workload controller reconciles Kubernetes Pods and Slurm Jobs. Slurm is the source of truth for what workload is allowed to run on which managed nodes.

sequenceDiagram
  autonumber

  participant KAPI as Kubernetes API
  participant SWC as Slurm Workload Controller
  participant SAPI as Slurm REST API

  loop Reconcile Loop

  critical Map Slurm Job to Pod
    KAPI-->>SWC: Watch Kubernetes Pods
    SAPI-->>SWC: Watch Slurm Jobs
  option Pod is Terminated
    SWC->>SAPI: Terminate Slurm Job
    SAPI-->>SWC: Return Status
  option Job is Terminated
    SWC->>KAPI: Evict Pod
    KAPI-->>SWC: Return Status
  end %% critical Map Slurm Job to Pod

  end %% loop Reconcile Loop

2.1.5 - Quickstart

Overview

This quickstart guide will help you get the slurm-bridge running and configured with your existing Slurm cluster.

Slurm Configuration

There are a set of assumptions that the slurm-bridge-scheduler must make. The Slurm admin must satisfy those assumption in their Slurm cluster.

  • There exists a set of hosts that have colocated kubelet and slurmd (installed on the same host, typically running as a systemd service).
  • Slurm is configured with a partition with that only contains host with colocated kubelet and slurmd.
    • The partition name must match the one configured in values.yaml used to deploy the slurm-bridge helm chart (default: “slurm-bridge”).
    • Example slurm.conf snippet.
      # slurm.conf
      ...
      NodeSet=kubernetes Feature=kubernetes
      PartitionName=slurm-bridge Nodes=kubernetes

  • In the event that the colocated node’s Slurm NodeName does not match the Kubernetes Node name, you should patch the Kubernetes node with a label to allow slurm-bridge to map the colocated Kubernetes and Slurm node.
    kubectl patch node $KUBERNETES_NODENAME -p "{\"metadata\":{\"labels\":{\"slinky.slurm.net/slurm-nodename\":\"$SLURM_NODENAME\"}}}"

  • Slurm has Multi-Category Security enabled for labels.
    • Example slurm.conf snippet.
    # slurm.conf
    ...
    MCSPlugin=mcs/label
    MCSParameters=ondemand,ondemandselect


Install slurm-bridge

Pre-Requisites

Install the pre-requisite helm charts.

helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true

Slurm Bridge

Download values and install the slurm-bridge from OCI package:

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-bridge/refs/tags/v0.2.0/helm/slurm-bridge/values.yaml \
  -o values-bridge.yaml
helm install slurm-bridge oci://ghcr.io/slinkyproject/charts/slurm-bridge \
  --values=values-bridge.yaml --version=0.3.0 --namespace=slinky --create-namespace

You can check if your cluster deployed successfully with:

kubectl --namespace=slinky get pods

Your output should be similar to:

NAME                                        READY   STATUS    RESTARTS      AGE
slurm-bridge-admission-85f89cf884-8c9jt     1/1     Running   0             1m0s
slurm-bridge-controllers-757f64b875-bsfnf   1/1     Running   0             1m0s
slurm-bridge-scheduler-5484467f55-wtspk     1/1     Running   0             1m0s

Scheduling Workload

Generally speaking, slurm-bridge translates one or more pods into a representative Slurm workload, where Slurm does the underlying scheduling. Certain optimizations can be made, depending on which resource is being translated.

slurm-bridge has specific scheduling support for JobSet and PodGroup resources and their pods. If your workload requires or benefits from co-scheduled pod launch (e.g. MPI, multi-node), consider representing your workload as a JobSet or PodGroup.

Admission Controller

slurm-bridge will only schedule pods who requests slurm-bridge as its scheduler. The slurm-bridge admission controller can be configured to automatically make slurm-bridge the scheduler for all pods created in the configured namespaces.

Alternatively, a pod can specify Pod.Spec.schedulerName=slurm-bridge-scheduler from any namespace.

Annotations

Users can better inform or influence slurm-bridge how to represent their Kubernetes workload within Slurm by adding annotations on the parent Object.

Example “pause” bare pod to illustrate annotations:

apiVersion: v1
kind: Pod
metadata:
  name: pause
  # slurm-bridge annotations on parent object
  annotations:
    slinky.slurm.net/timelimit: "5"
    slinky.slurm.net/account: foo
spec:
  schedulerName: slurm-bridge-scheduler
  containers:
    - name: pause
      image: registry.k8s.io/pause:3.6
      resources:
        limits:
          cpu: "1"
          memory: 100Mi

Example “pause” deployment to illustrate annotations:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: pause
  # slurm-bridge annotations on parent object
  annotations:
    slinky.slurm.net/timelimit: "5"
    slinky.slurm.net/account: foo
spec:
  replicas: 2
  selector:
    matchLabels:
      app: pause
  template:
    metadata:
      labels:
        app: pause
    spec:
      schedulerName: slurm-bridge-scheduler
      containers:
        - name: pause
          image: registry.k8s.io/pause:3.6
          resources:
            limits:
              cpu: "1"
              memory: 100Mi

JobSets

This section assumes JobSets is installed.

JobSet pods will be coscheduled and launched together. The JobSet controller is responsible for managing the JobSet status and other Pod interactions once marked as completed.

PodGroups

This section assumes PodGroups CRD is installed and the out-of-tree kube-scheduler is installed and configured as a (non-primary) scheduler.

Pods contained within a PodGroup will be co-scheduled and launched together. The PodGroup controller is responsible for managing the PodGroup status and other Pod interactions once marked as completed.

2.1.6 - Scheduler

Overview

The scheduler controller is responsible for scheduling pending pods onto nodes.

This scheduler is designed to be a non-primary scheduler (e.g. should not replace the default kube-scheduler). This means that only certain pods should be scheduled via this scheduler (e.g. non-critical pods).

This scheduler represents Kubernetes Pods as a Slurm Job, waits for Slurm to schedule the Job, then informs Kubernetes on which nodes to allocate the represented Pods. Tis scheduler defers scheduling decisions to Slurm, hence certain assumptions about the environment must be met for this to function correctly.

Sequence Diagram

sequenceDiagram
  autonumber

  actor user as User
  participant KAPI as Kubernetes API
  participant SBS as Slurm-Bridge Scheduler
  participant SAPI as Slurm REST API

  loop Workload Submission
    user->>KAPI: Submit Pod
    KAPI-->>user: Return Request Status
  end %% loop Workload Submission

  loop Scheduling Loop
    SBS->>KAPI: Get Next Pod in Workload Queue
    KAPI-->>SBS: Return Next Pod in Workload Queue

    note over SBS: Honor Slurm scheduling decision
    critical Lookup Slurm Placeholder Job
      SBS->>SAPI: Get Placeholder Job
      SAPI-->>SBS: Return Placeholder Job
    option Job is NotFound
      note over SBS: Translate Pod(s) into Slurm Job
      SBS->>SAPI: Submit Placeholder Job
      SAPI-->>SBS: Return Submit Status
    option Job is Pending
      note over SBS: Check again later...
      SBS->>SBS: Requeue
    option Job is Allocated
      note over SBS: Bind Pod(s) to Node(s) from the Slurm Job
      SBS->>KAPI: Bind Pod(s) to Node(s)
      KAPI-->>SBS: Return Bind Request Status
    end %% Lookup Slurm Placeholder Job
  end %% loop Scheduling Loop

3 - slurm-operator

slurm-operator

This project provides a framework that runs Slurm and Kubernetes.

Code Respository

The code repository can be accessed at https://github.com/SlinkyProject/slurm-operator

License

Copyright (C) SchedMD LLC.

Licensed under the Apache License, Version 2.0 you may not use project except in compliance with the license.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

3.1 - 0.1.x

3.1.1 - Overview

slurm-operator

This project provides a framework that runs Slurm in Kubernetes.

Overview

This project deploys Slurm on Kubernetes. These pods coexist with other running workloads on Kubernetes. This project provides controls over the Slurm cluster configuration and deployment, along with configurable autoscaling policy for Slurm compute nodes.

This project allows for much of the functionality within Slurm for workload management. This includes:

  • Priority scheduling: Determine job execution order based on priorities and weights such as age
  • Fair share: Resources are distributed equitably among users based on historical usage.
  • Quality of Service (QoS): set of policies, such as limits of resources, priorities, and preemption and backfilling.
  • Job accounting: Information for every job and job step executed
  • Job dependencies: Allow users to specify relationships between jobs, from start, succeed, fail, or a particular state.
  • Workflows with partitioning: Divide cluster resource into sections for job management

To best enable Slurm in Kubernetes, the project uses Custom Resources (CRs) and an Operator to extend Kubernetes with custom behaviors for Slurm clusters. In addition, Helm is used for managing the deployment of the various components of this project to Kubernetes.

Supported Slurm Versions

Slurm 24.05 Data parsers v40, v41

Quickstart

See the Quickstart Guide to install.

Overall Architecture

This is a basic architecture. A more in depth description can be found in the docs directory.


Known Issues

  • CGroups is currently disabled, due to difficulties getting core information into the pods.
  • Updates may be slow, due to needing to wait for sequencing before the slurm-controller can be deployed.

License

Copyright (C) SchedMD LLC.

Licensed under the Apache License, Version 2.0 you may not use project except in compliance with the license.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

3.1.2 - User

3.1.2.1 - Autoscaling

The slurm-operator may be configured to autoscale NodeSets pods based on Slurm metrics. This guide discusses how to configure autoscaling using KEDA.

Getting Started

Before attempting to autoscale NodeSets, Slinky should be fully deployed to a Kubernetes cluster and Slurm jobs should be able to run.

Dependencies

Autoscaling requires additional services that are not included in Slinky. Follow documentation to install Prometheus, Metrics Server, and KEDA.

Prometheus will install tools to report metrics and view them with Grafana. The Metrics Server is needed to report CPU and memory usage for tools like kubectl top. KEDA is recommended for autoscaling as it provides usability improvements over standard the Horizontal Pod Autoscaler (HPA).

To add KEDA in the helm install, run

helm repo add kedacore https://kedacore.github.io/charts

Install the slurm-exporter. This chart is installed as a dependency of the slurm helm chart by default. Configure using helm/slurm/values.yaml.

Verify KEDA Metrics API Server is running

$ kubectl get apiservice -l app.kubernetes.io/instance=keda
NAME                              SERVICE                                AVAILABLE   AGE
v1beta1.external.metrics.k8s.io   keda/keda-operator-metrics-apiserver   True        22h

KEDA provides the metrics apiserver required by HPA to scale on custom metrics from Slurm. An alternative like Prometheus Adapter could be used for this, but KEDA offers usability enhancements and improvements to HPA in addition to including a metrics apiserver.

Autoscaling

Autoscaling NodeSets allows Slurm partitions to expand and contract in response to the CPU and memory usage. Using Slurm metrics, NodeSets may also scale based on Slurm specific information like the number of pending jobs or the size of the largest pending job in a partition. There are many ways to configure autoscaling. Experiment with different combinations based on the types of jobs being run and the resources available in the cluster.

NodeSet Scale Subresource

Scaling a resource in Kuberenetes requires that resources such as Deployments and StatefulSets support the scale subresource. This is also true of the NodeSet Custom Resource.

The scale subresource gives a standard interface to observe and control the number of replicas of a resource. In the case of NodeSet, it allows Kubernetes and related services to control the number of slurmd replicas running as part of the NodeSet.

Note: NodeSets with replicas: null are intended to scale similar to a DaemonSet. This is not an appropriate type of NodeSet to use with Autoscaling as the Slinky operator will handle scaling NodeSet replicas across the cluster based on the selection criterea.

To manually scale a NodeSet, use the kubectl scale command. In this example, the NodeSet (nss) slurm-compute-radar is scaled to 1.

$ kubectl scale -n slurm nss/slurm-compute-radar --replicas=1
nodeset.slinky.slurm.net/slurm-compute-radar scaled

$ kubectl get pods -o wide -n slurm -l app.kubernetes.io/instance=slurm-compute-radar
NAME                        READY   STATUS    RESTARTS   AGE     IP            NODE          NOMINATED NODE   READINESS GATES
slurm-compute-radar-p8jwh   1/1     Running   0          2m48s   10.244.4.17   kind-worker   <none>           <none>

This corresponds to the Slurm partition radar.

$ kubectl exec -n slurm statefulset/slurm-controller -- sinfo
PARTITION AVAIL  TIMELIMIT  NODES  STATE NODELIST
radar        up   infinite      1   idle kind-worker

NodeSets may be scaled to zero. In this case, there are no replicas of slurmd running and all jobs scheduled to that partition will remain in a pending state.

$ kubectl scale nss/slurm-compute-radar -n slurm --replicas=0
nodeset.slinky.slurm.net/slurm-compute-radar scaled

For NodeSets to scale on demand, an autoscaler needs to be deployed. KEDA allows resources to scale from 0<->1 and also creates an HPA to scale based on scalers like Prometheus and more.

KEDA ScaledObject

KEDA uses the Custom Resource ScaledObject to monitor and scale a resource. It will automatically create the HPA needed to scale based on external triggers like Prometheus. With Slurm metrics, NodeSets may be scaled based on data collected from the Slurm restapi.

This example ScaledObject will watch the number of jobs pending for the partition radar and scale the NodeSet slurm-compute-radar until a threshold value is satisfied or maxReplicaCount is reached.

apiVersion: keda.sh/v1alpha1
kind: ScaledObject
metadata:
  name: scale-radar
spec:
  scaleTargetRef:
    apiVersion: slinky.slurm.net/v1alpha1
    kind: NodeSet
    name: slurm-compute-radar
  idleReplicaCount: 0
  minReplicaCount: 1
  maxReplicaCount: 3
  triggers:
    - type: prometheus
      metricType: Value
      metadata:
        serverAddress: http://prometheus-kube-prometheus-prometheus.prometheus:9090
        query: slurm_partition_pending_jobs{partition="radar"}
        threshold: "5"

Note: The Prometheus trigger is using metricType: Value instead of the default AverageValue. AverageValue calculates the replica count by averaging the threshold across the current replica count.

Check [ScaledObject] documentation for a full list of allowable options.

In this scenario, the ScaledObject scale-radar will query the Slurm metric slurm_partition_pending_jobs from Prometheus with the label partition="radar".

When there is activity on the trigger (at least one pending job), KEDA will scale the NodeSet to minReplicaCount and then let HPA handle scaling up to maxReplicaCount or back down to minReplicaCount. When there is no activity on the trigger after a configurable amount of time, KEDA will scale the NodeSet to idleReplicaCount. See the KEDA documentation on idleReplicaCount for more examples.

Note: The only supported value for idleReplicaCount is 0 due to limitations on how the HPA controller works.

To verify a KEDA ScaledObject, apply it to the cluster in the appropriate namespace on a NodeSet that has no replicas.

$ kubectl scale nss/slurm-compute-radar -n slurm --replicas=0
nodeset.slinky.slurm.net/slurm-compute-radar scaled

Wait for Slurm to report that the partition has no nodes.

$ slurm@slurm-controller-0:/tmp$ sinfo -p radar
PARTITION AVAIL  TIMELIMIT  NODES  STATE NODELIST
radar        up   infinite      0    n/a

Apply the ScaledObject using kubectl to the correct namespace and verify the KEDA and HPA resources are created.

$ kubectl apply -f scaledobject.yaml -n slurm
scaledobject.keda.sh/scale-radar created

$ kubectl get -n slurm scaledobjects
NAME           SCALETARGETKIND                     SCALETARGETNAME        MIN   MAX   TRIGGERS     AUTHENTICATION   READY   ACTIVE   FALLBACK   PAUSED    AGE
scale-radar    slinky.slurm.net/v1alpha1.NodeSet   slurm-compute-radar    1     5     prometheus                    True    False    Unknown    Unknown   28s

$ kubectl get -n slurm hpa
NAME                    REFERENCE                      TARGETS       MINPODS   MAXPODS   REPLICAS   AGE
keda-hpa-scale-radar    NodeSet/slurm-compute-radar    <unknown>/5   1         5         0          32s

Once the [ScaledObject] and HPA are created, initiate some jobs to test that the NodeSet scale subresource is scaled in response.

$ sbatch --wrap "sleep 30" --partition radar --exclusive

The NodeSet will scale to minReplicaCount in response to activity on the trigger. Once the number of pending jobs crosses the configured threshold (submit more exclusive jobs to the partition), more replicas will be created to handle the additional demand. Until the threshold is exceeded, the NodeSet will remain at minReplicaCount.

Note: This example only works well for single node jobs, unless threshold is set to 1. In this case, HPA will continue to scale up NodeSet as long as there is a pending job until up until it reaches the maxReplicaCount.

After the default coolDownPeriod of 5 minutes without activity on the trigger, KEDA will scale the NodeSet down to 0.

3.1.2.2 - Slurm

Slurm

Slurm is an open source, fault-tolerant, and highly scalable cluster management and job scheduling system for large and small Linux clusters. Slurm requires no kernel modifications for its operation and is relatively self-contained. As a cluster workload manager, Slurm has three key functions. First, it allocates exclusive and/or non-exclusive access to resources (compute nodes) to users for some duration of time so they can perform work. Second, it provides a framework for starting, executing, and monitoring work (normally a parallel job) on the set of allocated nodes. Finally, it arbitrates contention for resources by managing a queue of pending work. Optional plugins can be used for accounting, advanced reservation, gang scheduling (time sharing for parallel jobs), backfill scheduling, topology optimized resource selection, resource limits by user or bank account, and sophisticated multifactor job prioritization algorithms.

Architecture

Slurm Architecture

See the Slurm architecture docs for more information.

3.1.3 - Dev

3.1.3.1 - Architecture

Overview

This document describes the high-level architecture of the Slinky slurm-operator.

Big Picture


The slurm-operator follows the Kubernetes operator pattern.

Operators are software extensions to Kubernetes that make use of custom resources to manage applications and their components. Operators follow Kubernetes principles, notably the control loop.

The slurm-operator has one controller for each Custom Resource Definition (CRD) that it is responsible to manage. Each controller has a control loop where the state of the Custom Resource (CR) is reconciled.

Often, an operator is only concerned about data reported by the Kubernetes API. In our case, we are also concerned about data reported by the Slurm API, which influences how the slurm-operator reconciles certain CRs.

Directory Map

This project follows the conventions of:

api/

Contains Custom Kubernetes API definitions. These become Custom Resource Definitions (CRDs) and are installed into a Kubernetes cluster.

cmd/

Contains code to be compiled into binary commands.

config/

Contains yaml configuration files used for kustomize deployments.

docs/

Contains project documentation.

hack/

Contains files for development and Kubebuilder. This includes a kind.sh script that can be used to create a kind cluster with all pre-requisites for local testing.

helm/

Contains helm deployments, including the configuration files such as values.yaml.

Helm is the recommended method to install this project into your Kubernetes cluster.

internal/

Contains code that is used internally. This code is not externally importable.

internal/controller/

Contains the controllers.

Each controller is named after the Custom Resource Definition (CRD) it manages. Currently, this consists of the nodeset and the cluster CRDs.

3.1.3.2 - Cluster Control

Overview

This controller is responsible for managing and reconciling the Cluster CRD. A CRD represents communication to a Slurm cluster via slurmrestd and auth/jwt.

This controller uses the Slurm client library.

Sequence Diagram

sequenceDiagram
    autonumber

    actor User as User
    participant KAPI as Kubernetes API
    participant CC as Cluster Controller
    box Operator Internals
        participant SCM as Slurm Client Map
        participant SEC as Slurm Event Channel
    end %% Operator Internals

    note over KAPI: Handle CR Creation
    User->>KAPI: Create Cluster CR
    KAPI-->>CC: Watch Cluster CRD
    CC->>+KAPI: Get referenced secret
    KAPI-->>-CC: Return secret
    create participant SC as Slurm Client
    CC->>+SC: Create Slurm Client for Cluster
    SC-->>-CC: Return Slurm Client Status
    loop Watch Slurm Nodes
        SC->>+SAPI: Get Slurm Nodes
        SAPI-->>-SC: Return Slurm Nodes
        SC->>SEC: Add Event for Cache Delta
    end %% loop Watch Slurm Nodes
    CC->>SCM: Add Slurm Client to Map
    CC->>+SC: Ping Slurm Control Plane
    SC->>+SAPI: Ping Slurm Control Plane
    SAPI-->>-SC: Return Ping
    SC-->>-CC: Return Ping
    CC->>KAPI: Update Cluster CR Status

    note over KAPI: Handle CR Deletion
    User->>KAPI: Delete Cluster CR
    KAPI-->>CC: Watch Cluster CRD
    SCM-->>CC: Lookup Slurm Client
    destroy SC
    CC-)SC: Shutdown Slurm Client
    CC->>SCM: Remove Slurm Client from Map

    participant SAPI as Slurm REST API

3.1.3.3 - Develop

This document aims to provide enough information that you can get started with development on this project.

Getting Started

You will need a Kubernetes cluster to run against. You can use KIND to get a local cluster for testing, or run against your choice of remote cluster.

Note: Your controller will automatically use the current context in your kubeconfig file (i.e. whatever cluster kubectl cluster-info shows).

Dependencies

Install KIND and Golang binaries for pre-commit hooks.

sudo apt-get install golang
make install

Pre-Commit

Install pre-commit and install the git hooks.

sudo apt-get install pre-commit
pre-commit install

Docker

Install Docker and configure rootless Docker.

After, test that your user account and communicate with docker.

docker run hello-world

Helm

Install Helm.

sudo snap install helm --classic

Skaffold

Install Skaffold.

curl -Lo skaffold https://storage.googleapis.com/skaffold/releases/latest/skaffold-linux-amd64 && \
sudo install skaffold /usr/local/bin/

If google-cloud-sdk is installed, skaffold is available as an additional component.

sudo apt-get install -y google-cloud-cli-skaffold

Kubernetes Client

Install kubectl.

sudo snap install kubectl --classic

If google-cloud-sdk is installed, kubectl is available as an additional component.

sudo apt-get install -y kubectl

Running on the Cluster

For development, all Helm deployments use a values-dev.yaml. If they do not exist in your environment yet or you are unsure, safely copy the values.yaml as a base by running:

make values-dev

Automatic

You can use Skaffold to build and push images, and deploy components using:

cd helm/slurm-operator/
skaffold run

NOTE: The skaffold.yaml is configured to inject the image and tag into the values-dev.yaml so they are correctly referenced.

Operator

The slurm operator aims to follow the Kubernetes Operator pattern.

It uses Controllers, which provide a reconcile function responsible for synchronizing resources until the desired state is reached on the cluster.

Install CRDs

When deploying a helm chart with skaffold or helm, the CRDs defined in its crds/ directory will be installed if not already present in the cluster.

Uninstall CRDs

To delete the Operator CRDs from the cluster:

make uninstall

WARNING: CRDs do not upgrade! The old ones must be uninstalled first so the new ones can be installed. This should only be done in development.

Modifying the API Definitions

If you are editing the API definitions, generate the manifests such as CRs or CRDs using:

make manifests

Slurm Version Changed

If the Slurm version has changed, generate the new OpenAPI spec and its golang client code using:

make generate

NOTE: Update code interacting with the API in accordance with the slurmrestd plugin lifecycle.

Running the operator locally

Install the operator’s CRDs with make install.

Launch the operator via the VSCode debugger using the “Launch Operator” launch task.

Because the operator will be running outside of Kubernetes and needs to communicate to the Slurm cluster, set the following options in you Slurm helm chart’s values.yaml:

  • debug.enable=true
  • debug.localOperator=true

If running on a Kind cluster, also set:

  • debug.disableCgroups=true

If the Slurm helm chart is being deployed with skaffold, run skaffold run --port-forward --tail. It is configured to automatically port-forward the restapi for the local operator to communicate with the Slurm cluster.

If skaffold is not used, manually run kubectl port-forward --namespace slurm services/slurm-restapi 6820:6820 for the local operator to communicate with the Slurm cluster.

After starting the operator, verify it is able to contact the Slurm cluster by checking that the Cluster CR has been marked ready:

$ kubectl get --namespace slurm clusters.slinky.slurm.net
NAME     READY   AGE
slurm    true    110s

See skaffold port-forwarding to learn how skaffold automatically detects which services to forward.

3.1.3.4 - NodeSet Controller

Overview

The nodeset controller is responsible for managing and reconciling the NodeSet CRD, which represents a set of homogeneous Slurm Nodes.

Design

This controller is responsible for managing and reconciling the NodeSet CRD. In addition to the regular responsibility of managing resources in Kubernetes via the Kubernetes API, this controller should take into consideration the state of Slurm to make certain reconciliation decisions.

Sequence Diagram

sequenceDiagram
    autonumber

    actor User as User
    participant KAPI as Kubernetes API
    participant NS as NodeSet Controller
    box Operator Internals
        participant SCM as Slurm Client Map
        participant SEC as Slurm Event Channel
    end %% Operator Internals
    participant SC as Slurm Client
    participant SAPI as Slurm REST API

    loop Watch Slurm Nodes
        SC->>+SAPI: Get Slurm Nodes
        SAPI-->>-SC: Return Slurm Nodes
        SC->>SEC: Add Event for Cache Delta
    end %% loop Watch Slurm Nodes

    note over KAPI: Handle CR Update
    SEC-->>NS: Watch Event Channel
    User->>KAPI: Update NodeSet CR
    KAPI-->>NS: Watch NodeSet CRD
    opt Scale-out Replicas
        NS->>KAPI: Create Pods
    end %% Scale-out Replicas
    opt Scale-in Replicas
        SCM-->>NS: Lookup Slurm Client
        NS->>+SC: Drain Slurm Node
        SC->>+SAPI: Drain Slurm Node
        SAPI-->>-SC: Return Drain Slurm Node Status
        SC-->>-NS: Drain Slurm Node
        alt Slurm Node is Drained
            NS->>KAPI: Delete Pod
        else
            NS->>NS: Check Again Later
        end %% alt Slurm Node is Drained
    end %% opt Scale-in Replicas

3.1.4 - Quickstart Guides

3.1.4.1 - Basic Quickstart

QuickStart Guide

Overview

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to Kubernetes.

Install

Pre-Requiisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
	--namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator from OCI package.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.1.0/helm/slurm-operator/values.yaml \
  -o values-operator.yaml
helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
  --values=values-operator.yaml --version=0.1.0 --namespace=slinky --create-namespace

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster from OCI package.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.1.0/helm/slurm/values.yaml \
  -o values-slurm.yaml
helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
  --values=values-slurm.yaml --version=0.1.0 --namespace=slurm --create-namespace

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-0             1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.1.4.2 - QuickStart Guide for Google GKE

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to GKE.

Setup

Setup a cluster on GKE.

gcloud container clusters create slinky-cluster \
    --location=us-central1-a \
    --num-nodes=2 \
    --node-taints "" \
    --machine-type=c2-standard-16

Setup kubectl to point to your new cluster.

gcloud container clusters get-credentials slinky-cluster

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add kedacore https://kedacore.github.io/charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator from OCI package.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.1.0/helm/slurm-operator/values.yaml \
    -o values-operator.yaml
helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
    --version 0.1.0 \
    -f values-operator.yaml \
    --namespace=slinky \
    --create-namespace

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster from OCI package.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.1.0/helm/slurm/values.yaml \
    -o values-slurm.yaml
helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
    --version 0.1.0 \
    -f values-slurm.yaml \
    --namespace=slurm \
    --create-namespace

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-l4bd2         1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.1.4.3 - QuickStart Guide for Microsoft AKS

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to AKS.

Setup

Setup a resource group on AKS

az group create --name slinky --location westus2

Setup a cluster on AKS

az aks create \
    --resource-group slinky \
    --name slinky \
    --location westus2 \
    --node-vm-size Standard_D2s_v3

Setup kubectl to point to your new cluster.

az aks get-credentials --resource-group slinky --name slinky

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add kedacore https://kedacore.github.io/charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator from OCI package.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.1.0/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
    --version 0.1.0 \
    -f values-operator.yaml \
    --namespace=slinky \
    --create-namespace

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster from OCI package.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.1.0/helm/slurm/values.yaml \
    -o values-slurm.yaml

By default the values-slurm.yaml file uses standard for controller.persistence.storageClass and mariadb.primary.persistence.storageClass. You will need to update this value to default to use AKS’s default storageClass.

helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
    --version 0.1.0 \
    -f values-slurm.yaml \
    --namespace=slurm \
    --create-namespace

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-l4bd2         1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.2 - 0.2.x

3.2.1 - Overview

slurm-operator

This project provides a framework that runs Slurm in Kubernetes.

Overview

This project deploys Slurm on Kubernetes. These pods coexist with other running workloads on Kubernetes. This project provides controls over the Slurm cluster configuration and deployment, along with configurable autoscaling policy for Slurm compute nodes. This project allows for much of the functionality within Slurm for workload management. This includes:

  • Priority scheduling: Determine job execution order based on priorities and weights such as age
  • Fair share: Resources are distributed equitably among users based on historical usage.
  • Quality of Service (QoS): set of policies, such as limits of resources, priorities, and preemption and backfilling.
  • Job accounting: Information for every job and job step executed
  • Job dependencies: Allow users to specify relationships between jobs, from start, succeed, fail, or a particular state.
  • Workflows with partitioning: Divide cluster resource into sections for job management

To best enable Slurm in Kubernetes, the project uses Custom Resources (CRs) and an Operator to extend Kubernetes with custom behaviors for Slurm clusters. In addition, Helm is used for managing the deployment of the various components of this project to Kubernetes.

Supported Slurm Versions

Data Parser: v41

  • 24.05
  • 24.11

Quickstart

See the Quickstart Guide to install.

Overall Architecture

This is a basic architecture. A more in depth description can be found in the docs directory.


Known Issues

  • slurmd fails to dynamically register with its pod’s resource limits.
    • slurmd currently registers and assets the host machine’s resources instead of its pod resource limits.
  • slurmd fails to start with cgroups enforcement enabled within a pod.
    • cgroup.conf is forced to CgroupPlugin=disabled to avoid init failure.

License

Copyright (C) SchedMD LLC.

Licensed under the Apache License, Version 2.0 you may not use project except in compliance with the license.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

3.2.2 - Architecture

Overview

This document describes the high-level architecture of the Slinky slurm-operator.

Big Picture


The slurm-operator follows the Kubernetes operator pattern.

Operators are software extensions to Kubernetes that make use of custom resources to manage applications and their components. Operators follow Kubernetes principles, notably the control loop.

The slurm-operator has one controller for each Custom Resource Definition (CRD) that it is responsible to manage. Each controller has a control loop where the state of the Custom Resource (CR) is reconciled.

Often, an operator is only concerned about data reported by the Kubernetes API. In our case, we are also concerned about data reported by the Slurm API, which influences how the slurm-operator reconciles certain CRs.

Directory Map

This project follows the conventions of:

api/

Contains Custom Kubernetes API definitions. These become Custom Resource Definitions (CRDs) and are installed into a Kubernetes cluster.

cmd/

Contains code to be compiled into binary commands.

config/

Contains yaml configuration files used for kustomize deployments.

docs/

Contains project documentation.

hack/

Contains files for development and Kubebuilder. This includes a kind.sh script that can be used to create a kind cluster with all pre-requisites for local testing.

helm/

Contains helm deployments, including the configuration files such as values.yaml.

Helm is the recommended method to install this project into your Kubernetes cluster.

internal/

Contains code that is used internally. This code is not externally importable.

internal/controller/

Contains the controllers.

Each controller is named after the Custom Resource Definition (CRD) it manages. Currently, this consists of the nodeset and the cluster CRDs.

3.2.3 - Autoscaling

The slurm-operator may be configured to autoscale NodeSets pods based on Slurm metrics. This guide discusses how to configure autoscaling using KEDA.

Getting Started

Before attempting to autoscale NodeSets, Slinky should be fully deployed to a Kubernetes cluster and Slurm jobs should be able to run.

Dependencies

Autoscaling requires additional services that are not included in Slinky. Follow documentation to install Prometheus, Metrics Server, and KEDA.

Prometheus will install tools to report metrics and view them with Grafana. The Metrics Server is needed to report CPU and memory usage for tools like kubectl top. KEDA is recommended for autoscaling as it provides usability improvements over standard the Horizontal Pod Autoscaler (HPA).

To add KEDA in the helm install, run

helm repo add kedacore https://kedacore.github.io/charts

Install the slurm-exporter. This chart is installed as a dependency of the slurm helm chart by default. Configure using helm/slurm/values.yaml.

Verify KEDA Metrics API Server is running

$ kubectl get apiservice -l app.kubernetes.io/instance=keda
NAME                              SERVICE                                AVAILABLE   AGE
v1beta1.external.metrics.k8s.io   keda/keda-operator-metrics-apiserver   True        22h

KEDA provides the metrics apiserver required by HPA to scale on custom metrics from Slurm. An alternative like Prometheus Adapter could be used for this, but KEDA offers usability enhancements and improvements to HPA in addition to including a metrics apiserver.

Autoscaling

Autoscaling NodeSets allows Slurm partitions to expand and contract in response to the CPU and memory usage. Using Slurm metrics, NodeSets may also scale based on Slurm specific information like the number of pending jobs or the size of the largest pending job in a partition. There are many ways to configure autoscaling. Experiment with different combinations based on the types of jobs being run and the resources available in the cluster.

NodeSet Scale Subresource

Scaling a resource in Kuberenetes requires that resources such as Deployments and StatefulSets support the scale subresource. This is also true of the NodeSet Custom Resource.

The scale subresource gives a standard interface to observe and control the number of replicas of a resource. In the case of NodeSet, it allows Kubernetes and related services to control the number of slurmd replicas running as part of the NodeSet.

To manually scale a NodeSet, use the kubectl scale command. In this example, the NodeSet (nss) slurm-compute-radar is scaled to 1.

$ kubectl scale -n slurm nss/slurm-compute-radar --replicas=1
nodeset.slinky.slurm.net/slurm-compute-radar scaled

$ kubectl get pods -o wide -n slurm -l app.kubernetes.io/instance=slurm-compute-radar
NAME                    READY   STATUS    RESTARTS   AGE     IP            NODE          NOMINATED NODE   READINESS GATES
slurm-compute-radar-0   1/1     Running   0          2m48s   10.244.4.17   kind-worker   <none>           <none>

This corresponds to the Slurm partition radar.

$ kubectl exec -n slurm statefulset/slurm-controller -- sinfo
PARTITION AVAIL  TIMELIMIT  NODES  STATE NODELIST
radar        up   infinite      1   idle kind-worker

NodeSets may be scaled to zero. In this case, there are no replicas of slurmd running and all jobs scheduled to that partition will remain in a pending state.

$ kubectl scale nss/slurm-compute-radar -n slurm --replicas=0
nodeset.slinky.slurm.net/slurm-compute-radar scaled

For NodeSets to scale on demand, an autoscaler needs to be deployed. KEDA allows resources to scale from 0<->1 and also creates an HPA to scale based on scalers like Prometheus and more.

KEDA ScaledObject

KEDA uses the Custom Resource ScaledObject to monitor and scale a resource. It will automatically create the HPA needed to scale based on external triggers like Prometheus. With Slurm metrics, NodeSets may be scaled based on data collected from the Slurm restapi.

This example ScaledObject will watch the number of jobs pending for the partition radar and scale the NodeSet slurm-compute-radar until a threshold value is satisfied or maxReplicaCount is reached.

apiVersion: keda.sh/v1alpha1
kind: ScaledObject
metadata:
  name: scale-radar
spec:
  scaleTargetRef:
    apiVersion: slinky.slurm.net/v1alpha1
    kind: NodeSet
    name: slurm-compute-radar
  idleReplicaCount: 0
  minReplicaCount: 1
  maxReplicaCount: 3
  triggers:
    - type: prometheus
      metricType: Value
      metadata:
        serverAddress: http://prometheus-kube-prometheus-prometheus.prometheus:9090
        query: slurm_partition_pending_jobs{partition="radar"}
        threshold: "5"

Note: The Prometheus trigger is using metricType: Value instead of the default AverageValue. AverageValue calculates the replica count by averaging the threshold across the current replica count.

Check ScaledObject documentation for a full list of allowable options.

In this scenario, the ScaledObject scale-radar will query the Slurm metric slurm_partition_pending_jobs from Prometheus with the label partition="radar".

When there is activity on the trigger (at least one pending job), KEDA will scale the NodeSet to minReplicaCount and then let HPA handle scaling up to maxReplicaCount or back down to minReplicaCount. When there is no activity on the trigger after a configurable amount of time, KEDA will scale the NodeSet to idleReplicaCount. See the KEDA documentation on idleReplicaCount for more examples.

Note: The only supported value for idleReplicaCount is 0 due to limitations on how the HPA controller works.

To verify a KEDA ScaledObject, apply it to the cluster in the appropriate namespace on a NodeSet that has no replicas.

$ kubectl scale nss/slurm-compute-radar -n slurm --replicas=0
nodeset.slinky.slurm.net/slurm-compute-radar scaled

Wait for Slurm to report that the partition has no nodes.

$ slurm@slurm-controller-0:/tmp$ sinfo -p radar
PARTITION AVAIL  TIMELIMIT  NODES  STATE NODELIST
radar        up   infinite      0    n/a

Apply the ScaledObject using kubectl to the correct namespace and verify the KEDA and HPA resources are created.

$ kubectl apply -f scaledobject.yaml -n slurm
scaledobject.keda.sh/scale-radar created

$ kubectl get -n slurm scaledobjects
NAME           SCALETARGETKIND                     SCALETARGETNAME        MIN   MAX   TRIGGERS     AUTHENTICATION   READY   ACTIVE   FALLBACK   PAUSED    AGE
scale-radar    slinky.slurm.net/v1alpha1.NodeSet   slurm-compute-radar    1     5     prometheus                    True    False    Unknown    Unknown   28s

$ kubectl get -n slurm hpa
NAME                    REFERENCE                      TARGETS       MINPODS   MAXPODS   REPLICAS   AGE
keda-hpa-scale-radar    NodeSet/slurm-compute-radar    <unknown>/5   1         5         0          32s

Once the ScaledObject and HPA are created, initiate some jobs to test that the NodeSet scale subresource is scaled in response.

$ sbatch --wrap "sleep 30" --partition radar --exclusive

The NodeSet will scale to minReplicaCount in response to activity on the trigger. Once the number of pending jobs crosses the configured threshold (submit more exclusive jobs to the partition), more replicas will be created to handle the additional demand. Until the threshold is exceeded, the NodeSet will remain at minReplicaCount.

Note: This example only works well for single node jobs, unless threshold is set to 1. In this case, HPA will continue to scale up NodeSet as long as there is a pending job until up until it reaches the maxReplicaCount.

After the default coolDownPeriod of 5 minutes without activity on the trigger, KEDA will scale the NodeSet down to 0.

3.2.4 - Cluster Controller

Overview

This controller is responsible for managing and reconciling the Cluster CRD. A CRD represents communication to a Slurm cluster via slurmrestd and auth/jwt.

This controller uses the Slurm client library.

Sequence Diagram

sequenceDiagram
    autonumber

    actor User as User
    participant KAPI as Kubernetes API
    participant CC as Cluster Controller
    box Operator Internals
        participant SCM as Slurm Client Map
        participant SEC as Slurm Event Channel
    end %% Operator Internals

    note over KAPI: Handle CR Creation
    User->>KAPI: Create Cluster CR
    KAPI-->>CC: Watch Cluster CRD
    CC->>+KAPI: Get referenced secret
    KAPI-->>-CC: Return secret
    create participant SC as Slurm Client
    CC->>+SC: Create Slurm Client for Cluster
    SC-->>-CC: Return Slurm Client Status
    loop Watch Slurm Nodes
        SC->>+SAPI: Get Slurm Nodes
        SAPI-->>-SC: Return Slurm Nodes
        SC->>SEC: Add Event for Cache Delta
    end %% loop Watch Slurm Nodes
    CC->>SCM: Add Slurm Client to Map
    CC->>+SC: Ping Slurm Control Plane
    SC->>+SAPI: Ping Slurm Control Plane
    SAPI-->>-SC: Return Ping
    SC-->>-CC: Return Ping
    CC->>KAPI: Update Cluster CR Status

    note over KAPI: Handle CR Deletion
    User->>KAPI: Delete Cluster CR
    KAPI-->>CC: Watch Cluster CRD
    SCM-->>CC: Lookup Slurm Client
    destroy SC
    CC-)SC: Shutdown Slurm Client
    CC->>SCM: Remove Slurm Client from Map

    participant SAPI as Slurm REST API

3.2.5 - Develop

This document aims to provide enough information that you can get started with development on this project.

Getting Started

You will need a Kubernetes cluster to run against. You can use KIND to get a local cluster for testing, or run against your choice of remote cluster.

Note: Your controller will automatically use the current context in your kubeconfig file (i.e. whatever cluster kubectl cluster-info shows).

Dependencies

Install KIND and Golang binaries for pre-commit hooks.

sudo apt-get install golang
make install

Pre-Commit

Install pre-commit and install the git hooks.

sudo apt-get install pre-commit
pre-commit install

Docker

Install Docker and configure rootless Docker.

After, test that your user account and communicate with docker.

docker run hello-world

Helm

Install Helm.

sudo snap install helm --classic

Skaffold

Install Skaffold.

curl -Lo skaffold https://storage.googleapis.com/skaffold/releases/latest/skaffold-linux-amd64 && \
sudo install skaffold /usr/local/bin/

If google-cloud-sdk is installed, skaffold is available as an additional component.

sudo apt-get install -y google-cloud-cli-skaffold

Kubernetes Client

Install kubectl.

sudo snap install kubectl --classic

If google-cloud-sdk is installed, kubectl is available as an additional component.

sudo apt-get install -y kubectl

Running on the Cluster

For development, all Helm deployments use a values-dev.yaml. If they do not exist in your environment yet or you are unsure, safely copy the values.yaml as a base by running:

make values-dev

Automatic

You can use Skaffold to build and push images, and deploy components using:

cd helm/slurm-operator/
skaffold run

NOTE: The skaffold.yaml is configured to inject the image and tag into the values-dev.yaml so they are correctly referenced.

Operator

The slurm operator aims to follow the Kubernetes Operator pattern.

It uses Controllers, which provide a reconcile function responsible for synchronizing resources until the desired state is reached on the cluster.

Install CRDs

When deploying a helm chart with skaffold or helm, the CRDs defined in its crds/ directory will be installed if not already present in the cluster.

Uninstall CRDs

To delete the Operator CRDs from the cluster:

make uninstall

WARNING: CRDs do not upgrade! The old ones must be uninstalled first so the new ones can be installed. This should only be done in development.

Modifying the API Definitions

If you are editing the API definitions, generate the manifests such as CRs or CRDs using:

make manifests

Slurm Version Changed

If the Slurm version has changed, generate the new OpenAPI spec and its golang client code using:

make generate

NOTE: Update code interacting with the API in accordance with the slurmrestd plugin lifecycle.

Running the operator locally

Install the operator’s CRDs with make install.

Launch the operator via the VSCode debugger using the “Launch Operator” launch task.

Because the operator will be running outside of Kubernetes and needs to communicate to the Slurm cluster, set the following options in you Slurm helm chart’s values.yaml:

  • debug.enable=true
  • debug.localOperator=true

If running on a Kind cluster, also set:

  • debug.disableCgroups=true

If the Slurm helm chart is being deployed with skaffold, run skaffold run --port-forward --tail. It is configured to automatically port-forward the restapi for the local operator to communicate with the Slurm cluster.

If skaffold is not used, manually run kubectl port-forward --namespace slurm services/slurm-restapi 6820:6820 for the local operator to communicate with the Slurm cluster.

After starting the operator, verify it is able to contact the Slurm cluster by checking that the Cluster CR has been marked ready:

$ kubectl get --namespace slurm clusters.slinky.slurm.net
NAME     READY   AGE
slurm    true    110s

See skaffold port-forwarding to learn how skaffold automatically detects which services to forward.

3.2.6 - NodeSet Controller

Overview

The nodeset controller is responsible for managing and reconciling the NodeSet CRD, which represents a set of homogeneous Slurm Nodes.

Design

This controller is responsible for managing and reconciling the NodeSet CRD. In addition to the regular responsibility of managing resources in Kubernetes via the Kubernetes API, this controller should take into consideration the state of Slurm to make certain reconciliation decisions.

Sequence Diagram

sequenceDiagram
    autonumber

    actor User as User
    participant KAPI as Kubernetes API
    participant NS as NodeSet Controller
    box Operator Internals
        participant SCM as Slurm Client Map
        participant SEC as Slurm Event Channel
    end %% Operator Internals
    participant SC as Slurm Client
    participant SAPI as Slurm REST API

    loop Watch Slurm Nodes
        SC->>+SAPI: Get Slurm Nodes
        SAPI-->>-SC: Return Slurm Nodes
        SC->>SEC: Add Event for Cache Delta
    end %% loop Watch Slurm Nodes

    note over KAPI: Handle CR Update
    SEC-->>NS: Watch Event Channel
    User->>KAPI: Update NodeSet CR
    KAPI-->>NS: Watch NodeSet CRD
    opt Scale-out Replicas
        NS->>KAPI: Create Pods
    end %% Scale-out Replicas
    opt Scale-in Replicas
        SCM-->>NS: Lookup Slurm Client
        NS->>+SC: Drain Slurm Node
        SC->>+SAPI: Drain Slurm Node
        SAPI-->>-SC: Return Drain Slurm Node Status
        SC-->>-NS: Drain Slurm Node
        alt Slurm Node is Drained
            NS->>KAPI: Delete Pod
        else
            NS->>NS: Check Again Later
        end %% alt Slurm Node is Drained
    end %% opt Scale-in Replicas

3.2.7 - Slurm

Slurm

Slurm is an open source, fault-tolerant, and highly scalable cluster management and job scheduling system for large and small Linux clusters. Slurm requires no kernel modifications for its operation and is relatively self-contained. As a cluster workload manager, Slurm has three key functions. First, it allocates exclusive and/or non-exclusive access to resources (compute nodes) to users for some duration of time so they can perform work. Second, it provides a framework for starting, executing, and monitoring work (normally a parallel job) on the set of allocated nodes. Finally, it arbitrates contention for resources by managing a queue of pending work. Optional plugins can be used for accounting, advanced reservation, gang scheduling (time sharing for parallel jobs), backfill scheduling, topology optimized resource selection, resource limits by user or bank account, and sophisticated multifactor job prioritization algorithms.

Architecture

Slurm Architecture

See the Slurm architecture docs for more information.

3.2.8 - Quickstart Guides

3.2.8.1 - QuickStart Guide for Amazon EKS

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to Amazon EKS.

Setup

Setup a cluster on EKS.

eksctl create cluster \
    --name slinky-cluster \
    --region us-west-2 \
    --nodegroup-name slinky-nodes \
    --node-type t3.medium \
    --nodes 2

Setup kubectl to point to your new cluster.

aws eks --region us-west-2 update-kubeconfig --name slinky-cluster

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add kedacore https://kedacore.github.io/charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo add aws-ebs-csi-driver https://kubernetes-sigs.github.io/aws-ebs-csi-driver
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Install EBS CSI Driver

helm install aws-ebs-csi aws-ebs-csi-driver/aws-ebs-csi-driver -n kube-system

AWS Permissions

You will need to make sure your IAM user has the proper permissions.

Step 1: Identify the IAM Role

Run the following AWS CLI command to get the IAM role attached to your EKS worker nodes:

aws eks describe-nodegroup \
    --cluster-name slinky-cluster \
    --nodegroup-name slinky-nodes \
    --query "nodegroup.nodeRole" \
    --output text


This will return something like:

arn:aws:iam::017820679962:role/eksctl-slurm-cluster-nodegroup-my-nod-NodeInstanceRole-hpbRU4WRvvlK
The IAM role name here is eksctl-slurm-cluster-nodegroup-my-nod-NodeInstanceRole-hpbRU4WRvvlK.

Step 2: Attach the Required IAM Policy for EBS CSI Driver

Attach the AmazonEBSCSIDriverPolicy managed IAM policy to this role.

Run the following command:

aws iam attach-role-policy \
  --role-name eksctl-slurm-cluster-nodegroup-my-nod-NodeInstanceRole-hpbRU4WRvvlK \
  --policy-arn arn:aws:iam::aws:policy/service-role/AmazonEBSCSIDriverPolicy

Create StorageClass

You will need to create a StorageClass to use.

Here is an example storageclass.yaml file for a StorageClass

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: standard
provisioner: ebs.csi.aws.com
reclaimPolicy: Delete
volumeBindingMode: WaitForFirstConsumer
parameters:
  type: gp2
  fsType: ext4

Create the StorageClass using your storageclass.yaml file.

kubectl apply -f storageclass.yaml

Slurm Operator

Download values and install the slurm-operator. You will need to update the operator and webhook repository values to point to the desired container repository.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.2.1/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

helm install slurm-operator \
    -f values-operator.yaml \
    --namespace=slinky \
    --create-namespace \
    helm/slurm-operator

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.2.1/helm/slurm/values.yaml \
    -o values-slurm.yaml

helm install slurm \
    -f values-slurm.yaml \
    --namespace=slurm \
    --create-namespace \
    helm/slurm

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-l4bd2         1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.2.8.2 - QuickStart Guide for Google GKE

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to GKE.

Setup

Setup a cluster on GKE.

gcloud container clusters create slinky-cluster \
    --location=us-central1-a \
    --num-nodes=2 \
    --node-taints "" \
    --machine-type=c2-standard-16

Setup kubectl to point to your new cluster.

gcloud container clusters get-credentials slinky-cluster

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add kedacore https://kedacore.github.io/charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator. You will need to update the operator and webhook repository values to point to the desired container repository.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.2.1/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

helm install slurm-operator \
    -f values-operator.yaml \
    --namespace=slinky \
    --create-namespace \
    helm/slurm-operator

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.2.1/helm/slurm/values.yaml \
    -o values-slurm.yaml

helm install slurm \
    -f values-slurm.yaml \
    --namespace=slurm \
    --create-namespace \
    helm/slurm

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-l4bd2         1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.2.8.3 - QuickStart Guide for Microsoft AKS

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to AKS.

Setup

Setup a resource group on AKS

az group create --name slinky --location westus2

Setup a cluster on AKS

az aks create \
    --resource-group slinky \
    --name slinky \
    --location westus2 \
    --node-vm-size Standard_D2s_v3

Setup kubectl to point to your new cluster.

az aks get-credentials --resource-group slinky --name slinky

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add kedacore https://kedacore.github.io/charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator. You will need to update the operator and webhook repository values to point to the desired container repository.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.2.1/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

Make sure you are authenticated and the proper role is assigned to pull your images.

az acr login -n slinky

az aks show \
    --resource-group slinky \
    --name slinky \
    --query identityProfile.kubeletidentity.clientId \
    -o tsv

az role assignment create --assignee <clientId from above> \
     --role AcrPull \
     --scope $(az acr show --name slinky --query id -o tsv)

helm install slurm-operator \
    -f values-operator.yaml \
    --namespace=slinky \
    --create-namespace \
    helm/slurm-operator

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.2.1/helm/slurm/values.yaml \
    -o values-slurm.yaml

helm install slurm \
    -f values-slurm.yaml \
    --namespace=slurm \
    --create-namespace \
    helm/slurm

By default the values-slurm.yaml file uses standard for controller.persistence.storageClass and mariadb.primary.persistence.storageClass. You will need to update this value to default to use AKS’s default storageClass.

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-l4bd2         1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.3 - 0.3.x

3.3.1 - Overview

Overview

Slurm and Kubernetes are workload managers originally designed for different kinds of workloads. In broad strokes: Kubernetes excels at scheduling workloads that typically run for an indefinite amount of time, with potentially vague resource requirements, on a single node, with loose policy, but can scale its resource pool infinitely to meet demand; Slurm excels at quickly scheduling workloads that run for a finite amount of time, with well defined resource requirements and topology, on multiple nodes, with strict policy, but its resource pool is known.

This project enables the best of both workload managers, unified on Kubernetes. It contains a Kubernetes operator to deploy and manage certain components of Slurm clusters. This repository implements custom-controllers and custom resource definitions (CRDs) designed for the lifecycle (creation, upgrade, graceful shutdown) of Slurm clusters.

For additional architectural notes, see the architecture docs.

Slurm Cluster

Slurm clusters are very flexible and can be configured in various ways. Our Slurm helm chart provides a reference implementation that is highly customizable and tries to expose everything Slurm has to offer.

For additional information about Slurm, see the slurm docs.

Features

NodeSets

A set of homogeneous Slurm nodes (compute nodes, workers), which are delegated to execute the Slurm workload.

The operator will take into consideration the running workload among Slurm nodes as it needs to scale-in, upgrade, or otherwise handle node failures. Slurm nodes will be marked as drain before their eventual termination pending scale-in or upgrade.

The operator supports NodeSet scale to zero, scaling the resource down to zero replicas. Hence, any Horizontal Pod Autoscaler (HPA) that also support scale to zero can be best paired with NodeSets.

Slurm

Slurm is a full featured HPC workload manager. To highlight a few features:

  • Accounting: collect accounting information for every job and job step executed.
  • Partitions: job queues with sets of resources and constraints (e.g. job size limit, job time limit, users permitted).
  • Reservations: reserve resources for jobs being executed by select users and/or select accounts.
  • Job Dependencies: defer the start of jobs until the specified dependencies have been satisfied.
  • Job Containers: jobs which run an unprivileged OCI container bundle.
  • MPI: launch parallel MPI jobs, supports various MPI implementations.
  • Priority: assigns priorities to jobs upon submission and on an ongoing basis (e.g. as they age).
  • Preemption: stop one or more low-priority jobs to let a high-priority job run.
  • QoS: sets of policies affecting scheduling priority, preemption, and resource limits.
  • Fairshare: distribute resources equitably among users and accounts based on historical usage.
  • Node Health Check: periodically check node health via script.

Limitations

  • Kubernetes Version: >= v1.29
  • Slurm Version: >= 24.11

Installation

Install the slurm-operator:

helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
  --namespace=slinky --create-namespace

Install a Slurm cluster:

helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
  --namespace=slurm --create-namespace

For additional instructions, see the quickstart guide.

Upgrades

0.X Releases

Breaking changes may be introduced into newer CRDs. To upgrade between these versions, uninstall all Slinky charts and delete Slinky CRDs, then install the new release like normal.

helm --namespace=slurm uninstall slurm
helm --namespace=slinky uninstall slurm-operator
kubectl delete clusters.slinky.slurm.net
kubectl delete nodesets.slinky.slurm.net

Documentation

Project documentation is located in the docs directory of this repository.

Slinky documentation can be found here.

License

Copyright (C) SchedMD LLC.

Licensed under the Apache License, Version 2.0 you may not use project except in compliance with the license.

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

3.3.2 - Architecture

Overview

This document describes the high-level architecture of the Slinky slurm-operator.

Operator

The following diagram illustrates the operator, from a communication perspective.


The slurm-operator follows the Kubernetes operator pattern.

Operators are software extensions to Kubernetes that make use of custom resources to manage applications and their components. Operators follow Kubernetes principles, notably the control loop.

The slurm-operator has one controller for each Custom Resource Definition (CRD) that it is responsible to manage. Each controller has a control loop where the state of the Custom Resource (CR) is reconciled.

Often, an operator is only concerned about data reported by the Kubernetes API. In our case, we are also concerned about data reported by the Slurm API, which influences how the slurm-operator reconciles certain CRs.

Slurm

The following diagram illustrates a containerized Slurm cluster, from a communication perspective.


For additional information about Slurm, see the slurm docs.

Hybrid

The following hybrid diagram is an example. There are many different configurations for a hybrid setup. The core takeaways are: slurmd can be on bare-metal and still be joined to your containerized Slurm cluster; external services that your Slurm cluster needs or wants (e.g. AD/LDAP, NFS, MariaDB) do not have to live in Kubernetes to be functional with your Slurm cluster.


Autoscale

Kubernetes supports resource autoscaling. In the context of Slurm, autoscaling Slurm compute nodes can be quite useful when your Kubernetes and Slurm clusters have workload fluctuations.


See the autoscaling guide for additional information.

Directory Map

This project follows the conventions of:

api/

Contains Custom Kubernetes API definitions. These become Custom Resource Definitions (CRDs) and are installed into a Kubernetes cluster.

cmd/

Contains code to be compiled into binary commands.

config/

Contains yaml configuration files used for kustomize deployments.

docs/

Contains project documentation.

hack/

Contains files for development and Kubebuilder. This includes a kind.sh script that can be used to create a kind cluster with all pre-requisites for local testing.

helm/

Contains helm deployments, including the configuration files such as values.yaml.

Helm is the recommended method to install this project into your Kubernetes cluster.

internal/

Contains code that is used internally. This code is not externally importable.

internal/controller/

Contains the controllers.

Each controller is named after the Custom Resource Definition (CRD) it manages. Currently, this consists of the nodeset and the cluster CRDs.

3.3.3 - Autoscaling

Getting Started

Before attempting to autoscale NodeSets, Slinky should be fully deployed to a Kubernetes cluster and Slurm jobs should be able to run.

Dependencies

Autoscaling requires additional services that are not included in Slinky. Follow documentation to install Prometheus, Metrics Server, and KEDA.

Prometheus will install tools to report metrics and view them with Grafana. The Metrics Server is needed to report CPU and memory usage for tools like kubectl top. KEDA is recommended for autoscaling as it provides usability improvements over standard the Horizontal Pod Autoscaler (HPA).

To add KEDA in the helm install, run

helm repo add kedacore https://kedacore.github.io/charts

Install the slurm-exporter. This chart is installed as a dependency of the slurm helm chart by default. Configure using helm/slurm/values.yaml.

Verify KEDA Metrics API Server is running

$ kubectl get apiservice -l app.kubernetes.io/instance=keda
NAME                              SERVICE                                AVAILABLE   AGE
v1beta1.external.metrics.k8s.io   keda/keda-operator-metrics-apiserver   True        22h

KEDA provides the metrics apiserver required by HPA to scale on custom metrics from Slurm. An alternative like Prometheus Adapter could be used for this, but KEDA offers usability enhancements and improvements to HPA in addition to including a metrics apiserver.

Autoscaling

Autoscaling NodeSets allows Slurm partitions to expand and contract in response to the CPU and memory usage. Using Slurm metrics, NodeSets may also scale based on Slurm specific information like the number of pending jobs or the size of the largest pending job in a partition. There are many ways to configure autoscaling. Experiment with different combinations based on the types of jobs being run and the resources available in the cluster.

NodeSet Scale Subresource

Scaling a resource in Kubernetes requires that resources such as Deployments and StatefulSets support the scale subresource. This is also true of the NodeSet Custom Resource.

The scale subresource gives a standard interface to observe and control the number of replicas of a resource. In the case of NodeSet, it allows Kubernetes and related services to control the number of slurmd replicas running as part of the NodeSet.

To manually scale a NodeSet, use the kubectl scale command. In this example, the NodeSet (nss) slurm-compute-radar is scaled to 1.

$ kubectl scale -n slurm nss/slurm-compute-radar --replicas=1
nodeset.slinky.slurm.net/slurm-compute-radar scaled

$ kubectl get pods -o wide -n slurm -l app.kubernetes.io/instance=slurm-compute-radar
NAME                    READY   STATUS    RESTARTS   AGE     IP            NODE          NOMINATED NODE   READINESS GATES
slurm-compute-radar-0   1/1     Running   0          2m48s   10.244.4.17   kind-worker   <none>           <none>

This corresponds to the Slurm partition radar.

$ kubectl exec -n slurm statefulset/slurm-controller -- sinfo
PARTITION AVAIL  TIMELIMIT  NODES  STATE NODELIST
radar        up   infinite      1   idle kind-worker

NodeSets may be scaled to zero. In this case, there are no replicas of slurmd running and all jobs scheduled to that partition will remain in a pending state.

$ kubectl scale nss/slurm-compute-radar -n slurm --replicas=0
nodeset.slinky.slurm.net/slurm-compute-radar scaled

For NodeSets to scale on demand, an autoscaler needs to be deployed. KEDA allows resources to scale from 0<->1 and also creates an HPA to scale based on scalers like Prometheus and more.

KEDA ScaledObject

KEDA uses the Custom Resource ScaledObject to monitor and scale a resource. It will automatically create the HPA needed to scale based on external triggers like Prometheus. With Slurm metrics, NodeSets may be scaled based on data collected from the Slurm restapi.

This example ScaledObject will watch the number of jobs pending for the partition radar and scale the NodeSet slurm-compute-radar until a threshold value is satisfied or maxReplicaCount is reached.

apiVersion: keda.sh/v1alpha1
kind: ScaledObject
metadata:
  name: scale-radar
spec:
  scaleTargetRef:
    apiVersion: slinky.slurm.net/v1alpha1
    kind: NodeSet
    name: slurm-compute-radar
  idleReplicaCount: 0
  minReplicaCount: 1
  maxReplicaCount: 3
  triggers:
    - type: prometheus
      metricType: Value
      metadata:
        serverAddress: http://prometheus-kube-prometheus-prometheus.prometheus:9090
        query: slurm_partition_pending_jobs{partition="radar"}
        threshold: "5"

Note: The Prometheus trigger is using metricType: Value instead of the default AverageValue. AverageValue calculates the replica count by averaging the threshold across the current replica count.

Check ScaledObject documentation for a full list of allowable options.

In this scenario, the ScaledObject scale-radar will query the Slurm metric slurm_partition_pending_jobs from Prometheus with the label partition="radar".

When there is activity on the trigger (at least one pending job), KEDA will scale the NodeSet to minReplicaCount and then let HPA handle scaling up to maxReplicaCount or back down to minReplicaCount. When there is no activity on the trigger after a configurable amount of time, KEDA will scale the NodeSet to idleReplicaCount. See the KEDA documentation on idleReplicaCount for more examples.

Note: The only supported value for idleReplicaCount is 0 due to limitations on how the HPA controller works.

To verify a KEDA ScaledObject, apply it to the cluster in the appropriate namespace on a NodeSet that has no replicas.

$ kubectl scale nss/slurm-compute-radar -n slurm --replicas=0
nodeset.slinky.slurm.net/slurm-compute-radar scaled

Wait for Slurm to report that the partition has no nodes.

$ slurm@slurm-controller-0:/tmp$ sinfo -p radar
PARTITION AVAIL  TIMELIMIT  NODES  STATE NODELIST
radar        up   infinite      0    n/a

Apply the ScaledObject using kubectl to the correct namespace and verify the KEDA and HPA resources are created.

$ kubectl apply -f scaledobject.yaml -n slurm
scaledobject.keda.sh/scale-radar created

$ kubectl get -n slurm scaledobjects
NAME           SCALETARGETKIND                     SCALETARGETNAME        MIN   MAX   TRIGGERS     AUTHENTICATION   READY   ACTIVE   FALLBACK   PAUSED    AGE
scale-radar    slinky.slurm.net/v1alpha1.NodeSet   slurm-compute-radar    1     5     prometheus                    True    False    Unknown    Unknown   28s

$ kubectl get -n slurm hpa
NAME                    REFERENCE                      TARGETS       MINPODS   MAXPODS   REPLICAS   AGE
keda-hpa-scale-radar    NodeSet/slurm-compute-radar    <unknown>/5   1         5         0          32s

Once the ScaledObject and HPA are created, initiate some jobs to test that the NodeSet scale subresource is scaled in response.

$ sbatch --wrap "sleep 30" --partition radar --exclusive

The NodeSet will scale to minReplicaCount in response to activity on the trigger. Once the number of pending jobs crosses the configured threshold (submit more exclusive jobs to the partition), more replicas will be created to handle the additional demand. Until the threshold is exceeded, the NodeSet will remain at minReplicaCount.

Note: This example only works well for single node jobs, unless threshold is set to 1. In this case, HPA will continue to scale up NodeSet as long as there is a pending job until up until it reaches the maxReplicaCount.

After the default coolDownPeriod of 5 minutes without activity on the trigger, KEDA will scale the NodeSet down to 0.

3.3.4 - Cluster Controller

Overview

This controller is responsible for managing and reconciling the Cluster CRD. A CRD represents communication to a Slurm cluster via slurmrestd and auth/jwt.

This controller uses the Slurm client library.

Sequence Diagram

sequenceDiagram
    autonumber

    actor User as User
    participant KAPI as Kubernetes API
    participant CC as Cluster Controller
    box Operator Internals
        participant SCM as Slurm Client Map
        participant SEC as Slurm Event Channel
    end %% Operator Internals

    note over KAPI: Handle CR Creation
    User->>KAPI: Create Cluster CR
    KAPI-->>CC: Watch Cluster CRD
    CC->>+KAPI: Get referenced secret
    KAPI-->>-CC: Return secret
    create participant SC as Slurm Client
    CC->>+SC: Create Slurm Client for Cluster
    SC-->>-CC: Return Slurm Client Status
    loop Watch Slurm Nodes
        SC->>+SAPI: Get Slurm Nodes
        SAPI-->>-SC: Return Slurm Nodes
        SC->>SEC: Add Event for Cache Delta
    end %% loop Watch Slurm Nodes
    CC->>SCM: Add Slurm Client to Map
    CC->>+SC: Ping Slurm Control Plane
    SC->>+SAPI: Ping Slurm Control Plane
    SAPI-->>-SC: Return Ping
    SC-->>-CC: Return Ping
    CC->>KAPI: Update Cluster CR Status

    note over KAPI: Handle CR Deletion
    User->>KAPI: Delete Cluster CR
    KAPI-->>CC: Watch Cluster CRD
    SCM-->>CC: Lookup Slurm Client
    destroy SC
    CC-)SC: Shutdown Slurm Client
    CC->>SCM: Remove Slurm Client from Map

    participant SAPI as Slurm REST API

3.3.5 - Development

This document aims to provide enough information that you can get started with development on this project.

Getting Started

You will need a Kubernetes cluster to run against. You can use KIND to get a local cluster for testing, or run against your choice of remote cluster.

Note: Your controller will automatically use the current context in your kubeconfig file (i.e. whatever cluster kubectl cluster-info shows).

Dependencies

Install KIND and Golang binaries for pre-commit hooks.

sudo apt-get install golang
make install

Pre-Commit

Install pre-commit and install the git hooks.

sudo apt-get install pre-commit
pre-commit install

Docker

Install Docker and configure rootless Docker.

After, test that your user account and communicate with docker.

docker run hello-world

Helm

Install Helm.

sudo snap install helm --classic

Skaffold

Install Skaffold.

curl -Lo skaffold https://storage.googleapis.com/skaffold/releases/latest/skaffold-linux-amd64 && \
sudo install skaffold /usr/local/bin/

If google-cloud-sdk is installed, skaffold is available as an additional component.

sudo apt-get install -y google-cloud-cli-skaffold

Kubernetes Client

Install kubectl.

sudo snap install kubectl --classic

If google-cloud-sdk is installed, kubectl is available as an additional component.

sudo apt-get install -y kubectl

Running on the Cluster

For development, all Helm deployments use a values-dev.yaml. If they do not exist in your environment yet or you are unsure, safely copy the values.yaml as a base by running:

make values-dev

Automatic

You can use Skaffold to build and push images, and deploy components using:

cd helm/slurm-operator/
skaffold run

NOTE: The skaffold.yaml is configured to inject the image and tag into the values-dev.yaml so they are correctly referenced.

Operator

The slurm operator aims to follow the Kubernetes Operator pattern.

It uses Controllers, which provide a reconcile function responsible for synchronizing resources until the desired state is reached on the cluster.

Install CRDs

When deploying a helm chart with skaffold or helm, the CRDs defined in its crds/ directory will be installed if not already present in the cluster.

Uninstall CRDs

To delete the Operator CRDs from the cluster:

make uninstall

WARNING: CRDs do not upgrade! The old ones must be uninstalled first so the new ones can be installed. This should only be done in development.

Modifying the API Definitions

If you are editing the API definitions, generate the manifests such as CRs or CRDs using:

make manifests

Slurm Version Changed

If the Slurm version has changed, generate the new OpenAPI spec and its golang client code using:

make generate

NOTE: Update code interacting with the API in accordance with the slurmrestd plugin lifecycle.

Running the operator locally

Install the operator’s CRDs with make install.

Launch the operator via the VSCode debugger using the “Launch Operator” launch task.

Because the operator will be running outside of Kubernetes and needs to communicate to the Slurm cluster, set the following options in you Slurm helm chart’s values.yaml:

  • debug.enable=true
  • debug.localOperator=true

If running on a Kind cluster, also set:

  • debug.disableCgroups=true

If the Slurm helm chart is being deployed with skaffold, run skaffold run --port-forward --tail. It is configured to automatically port-forward the restapi for the local operator to communicate with the Slurm cluster.

If skaffold is not used, manually run kubectl port-forward --namespace slurm services/slurm-restapi 6820:6820 for the local operator to communicate with the Slurm cluster.

After starting the operator, verify it is able to contact the Slurm cluster by checking that the Cluster CR has been marked ready:

$ kubectl get --namespace slurm clusters.slinky.slurm.net
NAME     READY   AGE
slurm    true    110s

See skaffold port-forwarding to learn how skaffold automatically detects which services to forward.

Slurm Cluster

Get into a Slurm pod that can submit workload.

kubectl --namespace=slurm exec -it deployments/slurm-login -- bash -l
kubectl --namespace=slurm exec -it statefulsets/slurm-controller -- bash -l
cloud-provider-kind -enable-lb-port-mapping &
SLURM_LOGIN_PORT="$(kubectl --namespace=slurm get services -l app.kubernetes.io/name=login,app.kubernetes.io/instance=slurm -o jsonpath="{.items[0].status.loadBalancer.ingress[0].ports[0].port}")"
SLURM_LOGIN_IP="$(kubectl --namespace=slurm get services -l app.kubernetes.io/name=login,app.kubernetes.io/instance=slurm -o jsonpath="{.items[0].status.loadBalancer.ingress[0].ip}")"
ssh -p "$SLURM_LOGIN_PORT" "${USER}@${SLURM_LOGIN_IP}"

3.3.6 - NodeSet Controller

Overview

The nodeset controller is responsible for managing and reconciling the NodeSet CRD, which represents a set of homogeneous Slurm Nodes.

Design

This controller is responsible for managing and reconciling the NodeSet CRD. In addition to the regular responsibility of managing resources in Kubernetes via the Kubernetes API, this controller should take into consideration the state of Slurm to make certain reconciliation decisions.

Sequence Diagram

sequenceDiagram
    autonumber

    actor User as User
    participant KAPI as Kubernetes API
    participant NS as NodeSet Controller
    box Operator Internals
        participant SCM as Slurm Client Map
        participant SEC as Slurm Event Channel
    end %% Operator Internals
    participant SC as Slurm Client
    participant SAPI as Slurm REST API

    loop Watch Slurm Nodes
        SC->>+SAPI: Get Slurm Nodes
        SAPI-->>-SC: Return Slurm Nodes
        SC->>SEC: Add Event for Cache Delta
    end %% loop Watch Slurm Nodes

    note over KAPI: Handle CR Update
    SEC-->>NS: Watch Event Channel
    User->>KAPI: Update NodeSet CR
    KAPI-->>NS: Watch NodeSet CRD
    opt Scale-out Replicas
        NS->>KAPI: Create Pods
    end %% Scale-out Replicas
    opt Scale-in Replicas
        SCM-->>NS: Lookup Slurm Client
        NS->>+SC: Drain Slurm Node
        SC->>+SAPI: Drain Slurm Node
        SAPI-->>-SC: Return Drain Slurm Node Status
        SC-->>-NS: Drain Slurm Node
        alt Slurm Node is Drained
            NS->>KAPI: Delete Pod
        else
            NS->>NS: Check Again Later
        end %% alt Slurm Node is Drained
    end %% opt Scale-in Replicas

3.3.7 - Pyxis

Overview

This guide tells how to configure your Slurm cluster to use pyxis (and enroot), a Slurm SPANK plugin for containerized jobs with Nvidia GPU support.

Configure

Configure plugstack.conf to include the pyxis configuration.

Warning: In plugstack.conf, you must use glob syntax to avoid slurmctld failure while trying to resolve the paths in the includes. Only the login and slurmd pods should actually have the pyxis libraries installed.

slurm:
  configFiles:
    plugstack.conf: |
      include /usr/share/pyxis/*
  ...

Configure one or more NodeSets and the login pods to use a pyxis OCI image.

login:
  image:
    repository: ghcr.io/slinkyproject/login-pyxis
  ...
compute:
  nodesets:
    - name: debug
      image:
        repository: ghcr.io/slinkyproject/slurmd-pyxis
      ...

To make enroot activity in the login container permissible, it requires securityContext.privileged=true.

login:
  image:
    repository: ghcr.io/slinkyproject/login-pyxis
  securityContext:
    privileged: true

Test

Submit a job to a Slurm node.

$ srun --partition=debug grep PRETTY /etc/os-release
PRETTY_NAME="Ubuntu 24.04.2 LTS"

Submit a job to a Slurm node with pyxis and it will launch in its requested container.

$ srun --partition=debug --container-image=alpine:latest grep PRETTY /etc/os-release
pyxis: importing docker image: alpine:latest
pyxis: imported docker image: alpine:latest
PRETTY_NAME="Alpine Linux v3.21"

Warning: SPANK plugins will only work on specific Slurm node that have them and is configured to use them. It is best to constrain where jobs run with --partition=<partition>, --batch=<features>, and/or --constraint=<features> to ensure a compatible computing environment.

If the login container has securityContext.privileged=true, enroot activity is permissible. You can test the functionality with the following:

enroot import docker://alpine:latest

3.3.8 - Slurm

Slurm is an open source, fault-tolerant, and highly scalable cluster management and job scheduling system for large and small Linux clusters. Slurm requires no kernel modifications for its operation and is relatively self-contained. As a cluster workload manager, Slurm has three key functions. First, it allocates exclusive and/or non-exclusive access to resources (compute nodes) to users for some duration of time so they can perform work. Second, it provides a framework for starting, executing, and monitoring work (normally a parallel job) on the set of allocated nodes. Finally, it arbitrates contention for resources by managing a queue of pending work. Optional plugins can be used for accounting, advanced reservation, gang scheduling (time sharing for parallel jobs), backfill scheduling, topology optimized resource selection, resource limits by user or bank account, and sophisticated multifactor job prioritization algorithms.

Architecture

Slurm Architecture

See the Slurm architecture docs for more information.

3.3.9 - Quickstart Guides

3.3.9.1 - QuickStart Guide for Amazon EKS

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to Amazon EKS.

Setup

Setup a cluster on EKS.

eksctl create cluster \
 --name slinky-cluster \
 --region us-west-2 \
 --nodegroup-name slinky-nodes \
 --node-type t3.medium \
 --nodes 2

Setup kubectl to point to your new cluster.

aws eks --region us-west-2 update-kubeconfig --name slinky-cluster

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
    --namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Install EBS CSI Driver

helm install aws-ebs-csi aws-ebs-csi-driver/aws-ebs-csi-driver -n kube-system

AWS Permissions

You will need to make sure your IAM user has the proper permissions.

Step 1: Identify the IAM Role

Run the following AWS CLI command to get the IAM role attached to your EKS worker nodes:

aws eks describe-nodegroup \
    --cluster-name slinky-cluster \
    --nodegroup-name slinky-nodes \
    --query "nodegroup.nodeRole" \
    --output text

This will return something like:

arn:aws:iam::017820679962:role/eksctl-slurm-cluster-nodegroup-my-nod-NodeInstanceRole-hpbRU4WRvvlK
The IAM role name here is eksctl-slurm-cluster-nodegroup-my-nod-NodeInstanceRole-hpbRU4WRvvlK.

Step 2: Attach the Required IAM Policy for EBS CSI Driver

Attach the AmazonEBSCSIDriverPolicy managed IAM policy to this role.

Run the following command:

aws iam attach-role-policy \
    --role-name eksctl-slurm-cluster-nodegroup-my-nod-NodeInstanceRole-hpbRU4WRvvlK \
    --policy-arn arn:aws:iam::aws:policy/service-role/AmazonEBSCSIDriverPolicy

Create StorageClass

You will need to create a StorageClass to use.

Here is an example storageclass.yaml file for a StorageClass

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
    name: standard
provisioner: ebs.csi.aws.com
reclaimPolicy: Delete
volumeBindingMode: WaitForFirstConsumer
parameters:
    type: gp2
    fsType: ext4

Create the StorageClass using your storageclass.yaml file.

kubectl apply -f storageclass.yaml

Slurm Operator

Download values and install the slurm-operator. You will need to update the operator and webhook repository values to point to the desired container repository.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.3.0/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
    --values=values-operator.yaml --version=0.3.0 --namespace=slinky --create-namespace

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME READY STATUS RESTARTS AGE
slurm-operator-7444c844d5-dpr5h 1/1 Running 0 5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh 1/1 Running 0 5m00s

Slurm Cluster

Download values and install a Slurm cluster.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.3.0/helm/slurm/values.yaml \
    -o values-slurm.yaml

helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
    --values=values-slurm.yaml --version=0.3.0 --namespace=slurm --create-namespace

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                               READY   STATUS    RESTARTS   AGE
slurm-accounting-0                 1/1     Running   0          5m00s
slurm-compute-debug-0              1/1     Running   0          5m00s
slurm-controller-0                 2/2     Running   0          5m00s
slurm-exporter-7b44b6d856-d86q5    1/1     Running   0          5m00s
slurm-mariadb-0                    1/1     Running   0          5m00s
slurm-restapi-5f75db85d9-67gpl     1/1     Running   0          5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
 -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.3.9.2 - QuickStart Guide for Google GKE

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to GKE.

Setup

Setup a cluster on GKE.

gcloud container clusters create slinky-cluster \
    --location=us-central1-a \
    --num-nodes=2 \
    --node-taints "" \
    --machine-type=c2-standard-16

Setup kubectl to point to your new cluster.

gcloud container clusters get-credentials slinky-cluster

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator. You will need to update the operator and webhook repository values to point to the desired container repository.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.3.0/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
    --values=values-operator.yaml --version=0.3.0 --namespace=slinky --create-namespace

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.3.0/helm/slurm/values.yaml \
    -o values-slurm.yaml

helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
    --values=values-slurm.yaml --version=0.3.0 --namespace=slurm --create-namespace

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-0             1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.

3.3.9.3 - QuickStart Guide for Microsoft AKS

This quickstart guide will help you get the slurm-operator running and deploy Slurm clusters to AKS.

Setup

Setup a resource group on AKS

az group create --name slinky --location westus2

Setup a cluster on AKS

az aks create \
    --resource-group slinky \
    --name slinky \
    --location westus2 \
    --node-vm-size Standard_D2s_v3

Setup kubectl to point to your new cluster.

az aks get-credentials --resource-group slinky --name slinky

Pre-Requisites

Install the pre-requisite helm charts.

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo add jetstack https://charts.jetstack.io
helm repo update
helm install cert-manager jetstack/cert-manager \
	--namespace cert-manager --create-namespace --set crds.enabled=true
helm install prometheus prometheus-community/kube-prometheus-stack \
    --namespace prometheus --create-namespace --set installCRDs=true

Slurm Operator

Download values and install the slurm-operator. You will need to update the operator and webhook repository values to point to the desired container repository.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.3.0/helm/slurm-operator/values.yaml \
    -o values-operator.yaml

Make sure you are authenticated and the proper role is assigned to pull your images.

az acr login -n slinky

az aks show \
    --resource-group slinky \
    --name slinky \
    --query identityProfile.kubeletidentity.clientId \
    -o tsv

az role assignment create --assignee <clientId from above> \
     --role AcrPull \
     --scope $(az acr show --name slinky --query id -o tsv)

helm install slurm-operator oci://ghcr.io/slinkyproject/charts/slurm-operator \
    --values=values-operator.yaml --version=0.3.0 --namespace=slinky --create-namespace

Make sure the cluster deployed successfully with:

kubectl --namespace=slinky get pods

Output should be similar to:

NAME                                      READY   STATUS    RESTARTS   AGE
slurm-operator-7444c844d5-dpr5h           1/1     Running   0          5m00s
slurm-operator-webhook-6fd8d7857d-zcvqh   1/1     Running   0          5m00s

Slurm Cluster

Download values and install a Slurm cluster.

curl -L https://raw.githubusercontent.com/SlinkyProject/slurm-operator/refs/tags/v0.3.0/helm/slurm/values.yaml \
    -o values-slurm.yaml

By default the values-slurm.yaml file uses standard for controller.persistence.storageClass and mariadb.primary.persistence.storageClass. You will need to update this value to default to use AKS’s default storageClass.

helm install slurm oci://ghcr.io/slinkyproject/charts/slurm \
    --values=values-slurm.yaml --version=0.3.0 --namespace=slurm --create-namespace

Make sure the slurm cluster deployed successfully with:

kubectl --namespace=slurm get pods

Output should be similar to:

NAME                              READY   STATUS    RESTARTS       AGE
slurm-accounting-0                1/1     Running   0              5m00s
slurm-compute-debug-0             1/1     Running   0              5m00s
slurm-controller-0                2/2     Running   0              5m00s
slurm-exporter-7b44b6d856-d86q5   1/1     Running   0              5m00s
slurm-mariadb-0                   1/1     Running   0              5m00s
slurm-restapi-5f75db85d9-67gpl    1/1     Running   0              5m00s

Testing

To test Slurm functionality, connect to the controller to use Slurm client commands:

kubectl --namespace=slurm exec \
    -it statefulsets/slurm-controller -- bash --login

On the controller pod (e.g. host slurm@slurm-controller-0), run the following commands to quickly test Slurm is functioning:

sinfo
srun hostname
sbatch --wrap="sleep 60"
squeue

See Slurm Commands for more details on how to interact with Slurm.
